Hot Runner Turntable Machine

LPMS 900MD

Hot Runner Turntable Machine

Turntable design. One upper mold serves two bottom molds.
Melt-On-Demand tank melts the resin completely in 18 minutes, taking 6208 hot melt adhesive as example, temperature at 200 °C.
Equipped with dual 1 liter melting tank to fit different color resin or different model resin.
Hot runner system eliminates runner resin and improve productivity.
Built-in chiller.
The only independent dual dispensing low pressure molding system in the industry.
Injection pressure can be adjusted by the touch screen precisely.
Temp in different temp zones like tank, hose, hot runner, hot nozzles can be set independently.
Automatic feeding system and ejection system is equipped.

Application

Our machines are engineered for low pressure molding applications. Using specialty resins to encapsulate delicate parts.

Applications including : automotive electronics, PCBA，coil, fiber-optic, LED lighting, wire, cable, etc.

Specification

Machine Size (Width, Depth, Height) / Weight	1135 mm x 1442 mm x 1803 mm / 450 kg 44.69 in x 56.77 in x 70.98 in / 992 lbs
Working Station Height	850 mm \| 33.47 in
Footprint	1135 mm x 2100 mm \| 44.69 in x 82.67 in
Packaging Size (Width, Depth, Height) / Weight	1250 mm x 1560 mm x1850 mm / 500 kg 49.21 in x 61.42 in x 72.83 in / 1102 lbs
Melting Tank Model & Q'ty	MOD-01-900MD-DSAF x 2
Auto Feeding System	Ultrasonic
Gun Model & Tip	Hot Runner System
Each Station Gun Tip Q'ty	Std.4，depends on part design
Heated Hose Model & Q'ty	LPMS-H12J x 2
Electricity	200-240 VAC / 1 Phase / 50 Hz
Temperature Control Zones	9
Temperature Range	Ambient up to 250°C / 485°F
Max. Power	11 Kw
Min. Air Pressure	0.5 MPa \| 73 Psi
Air Consumption	0.1m³/min \| 3.53ft³ / min
Clamping Device	Air Cylinder
Clamping Force	Max.1.2 Tons
Clamping Stroke	75 mm \| 2.95 in
Ejector	Pneumatic
Ejector Force	2515 N
Ejector Stroke	25 mm　\|　0.98 in
Tooling Temp Control	Build-In Chiller
Control System	PLC+7 in HMI
Safety Protection	Light Curtain , Safety door
Standard Mold set Size/Weight	250 mm x 150 mm x 308mm / 75 kg 9.84 in x 5.91 in x12.13 in / 165 lbs
Max. Mold set Size	300 mm x 200 mm x 308 mm 11.81 in x7.87 in x12.13 in
Max. Part Size	60 mm x 50 mm x 18 mm 2.36 in x1.97 in x 0.71 in
